NVA-04S
The NVA-04S pugmill features newly designed twin augers and a forceful direct gear driven motor for remarkable extruding capability that produces air-free clay and increases clay workability. It features an all-stainless interior for use with porcelain and other light colored clay bodies. The high quality wedging and extruding capacity obtained makes this compact pugmill one of the most efficient and competitive on the market.
Features
-
- Direct gear driven motor provides maximum mechanical force for blending requiring minimum operator effort
- Twin cast stainless steel mixing augers blend and extrude up to 200 kg/hour
- Dual safety system; limit switch automatically cuts power to pugmill when augers are exposed. Stop button allows for immediate operator control
- Includes a clay cut-off wire, clay receiving table, and mounted on locking wheels
- Air vacuum pump system (oil-free)
Motor | Screw motor: Single phase, 230 V 400 w Pump motor: Single phase, 230 V, 250 W |
Extruding Capacity | 200 kg/hour |
Nozzle Diameter | 90 mm diameter |
Dimensions | 920 (1320 including clay roller stand) x 420 x 750 mm |
Weight | Main body 140 kg, Clay roller stand 5 kg |
Assorted Die
NIDEC-SHIMPO Pugmill extruding dies are made of stainless steel and fit any NRA-04, NVA-04S, and NVS-07 pugmill.
Contact your local dealer to order.
Coil Die
NIDEC-SHIMPO Pugmill extruding dies are made of stainless steel and fit any NRA-04, NVA-04S, and NVS-07 pugmill.
Contact your local dealer to order.
Tile Die
NIDEC-SHIMPO Pugmill extruding dies are made of stainless steel and fit any NRA-04, NVA-04S, and NVS-07 and pugmill.
Contact your local dealer to order.
Pugmill Die Set
NIDEC-SHIMPO Pugmill extruding dies are made of stainless steel and fit any NRA-04, NVA-04S, and NVS-07 pugmill. The set includes the Assorted Die P-DIE-ASRT-ASSY, Coil Die P-DIE-CYL-ASSY, and Tile Die P-DIE-TL-ASS.
Contact your local dealer to order.
